In addition to optimum soil and weather conditions, choosing the right seed drill technology is essential for perfect seed emergence. Pottinger‘s Terrasem mulch drilling concept combines tillage, consolidation, fertilizer application, and drilling in a single machine: the perfect combination of high output, reliability, and precision seed placement to meet farmers’ specifications.
Terrasem: he all-rounder for every situation
This newly designed seed drill with or without passive seedbed preparation delivers impressive performance with its precision universal metering and perfect colter system to guarantee exact seed placement. Flexible operation and being able to process up to three components simultaneously at a consistently high output translates into optimum drilling for the best seed emergence. The high-performance features of the Pottinger Terrasem increase yield capacity to boost the farmer’s profit. The new Terrasem will be available from November 2021.
The benefits are clear to see
- Highly flexible with injector metering or pressurized hopper metering system for successful sowing
- Robust construction with maximum output with working widths between 3 and 6 meters
- Coulter technology for large area output and a uniform, clean seed slot
- Suitable for mulch and direct mulch drilling as well as on plowed fields
Convenient operation without crabbing
A new configuration of the tillage tools ensures that the machine works 100 percent in a straight line. The disc harrow as well as the fertilizer colters (D Z-machine) and seed colters are mounted in an X configuration. Optimum seedbed preparation is ensured by the aggressive point angle of the lead tillage tools. There is no need to grease the tillage tools because they are mounted on sealed bearings.
Multiple sowing options
Single shoot, double shoot, and double shoot-mix are the key to perfect emergence. To match the site conditions and crop rotation of the customer, there is a wide choice between the application of seed, seed with fertilizer, and additional components such as micro-granulate, companion crop, or the second type of seed with the Terrasem D Z models. The different components can each be deposited at different depths.
Optimum plant density
The proven colter rail with a DUAL DISC colter system ensures an ideal plant density for the crop. With a row spacing of 12.5 cm as standard, or 16.7 cm as an option, optimum plant development is ensured and weeds are largely suppressed.
Two metering systems
Depending on the choice of machine, two different metering systems are available. The machines with a single hopper are equipped with injector metering – Terrasem 3000 D to V 6000 D as well as all Terrasem Classic models without tillage tools and without fertilizer application.
All Terrasem Z double seed hopper machines are equipped with a pressurized hopper system. The two-part hopper with a fixed 60:40 partition can also be filled with 100 percent seed. Integrated pressure differential sensors ensure the reliability of the system.
Source: Pottinger
